TotalSense Series

Indoor Environmental and Air Quality Sensor
Higher Reliability, Faster Installation, Superior Accuracy | Sense the Difference

TotalSense PM/VOC/CO2/RH/T/PIR Wall

Display, AQ ring, and standard PIR Motion Detection (optional) - Detect occupancy for quicker and safer ventilation Slim enclosure for more discreet sensing (display optional) - Slider and pushbuttons options available

Industry’s first IAQ sensor with PIR motion detection
Eight environmental sensors: PIR, PMx, VOC, CO2, RH, T, ambient light, barometric pressure
BACnet/Modbus or analog outputs with set-point relay
  • Reduce installation costs with multiple sensors in a standard size enclosure
  • Specify the exact product for your application with made in USA quality
  • Color display and Air Quality Ring for tenant assurance (programmable)
  • Initiate ventilation immediately upon occupancy detection for healthier buildings and energy savings
  • Sense unhealthy or offensive air with TVOC. Compensated for temperature and barometric pressure for total accuracy
  • Detect a variety of PM sizes to indicate airborne respiratory droplets, allergens, and other dangers
  • Industry-leading temperature and barometric pressure compensated CO2 sensing with non-dispersive infrared sensing element (NDIR), 15+ year life expectancy on CO2 sensing element; ±30ppm, ±3% of reading
  • Capacitive touch buttons make setup and use simple
  • Slim and sleek surface-mount enclosure is tamper-proof and easy to install
  • Field-replaceable PM, RH, Temp, and CO2 sensors ease maintenance
  • Set-point sliders and pushbuttons are also available to meet the requirements for any job
  • 7-year limited warranty / 3 years on CO2 sensor - 2 years on all others

Description

The TotalSense Series provides more data for more advanced ventilation control while drastically reducing installation cost and time on a project. It includes a comprehensive selection of IAQ sensing with carbon dioxide (CO2), relative humidity (RH), and temperature plus options for occupancy detection (PIR), total volatile organic compounds (TVOC), particulate matter (PM) and ambient light. More than an IAQ sensor, it’s the first fully configurable Indoor Environmental Quality (IEQ) sensor matrix. Motion detection (PIR) can initiate ventilation upon occupancy, providing air exchanges the instant people are present (in addition to monitored elevated CO2 levels.) This technology provides a much faster trigger for ventilation allowing for cleaner and safer indoor spaces while still saving energy. PIR and ambient light sensors can also be utilized for light harvesting for additional energy savings and code compliance.

Applications

  • Verify effectiveness of IAQ strategies in post covid environment
  • Energy management/building control
  • Facilitates compliance with ASHRAE 62.1 standard for air quality
  • Contributes toward satisfying Feature A08 and T06 under the WELL Building Standard®
Product Price Quantity
AQ2W-AA2VAAD Surf Wall,Anlg,VOC2%RH,OLED
$600.00 /

EA

AQ2W-AA2VAADP Surf Wall,Anlg,2%RH,VOC,PIRNo Tmp,OLED
$645.00 /

EA

AQ2W-AA2VAAR Surf Wall,Anlg,VOC,2%RH,NoTemp,LED
$570.00 /

EA

AQ2W-AA2VAARP Surf Wall,Anlg,2%RH,VOC,PIRNo Tmp,LED
$615.00 /

EA

AQ2W-AA2VAAS Surf Wall,Anlg,VOC2%RH,OLED+C
$600.00 /

EA

AQ2W-AA2VAASP Surf Wall,Anlg,2%RH,VOC,PIRNo Tmp,OLED+C
$645.00 /

EA

AQ2W-AA2VAAX Surf Wall,Anlg,VOC2%RH
$525.00 /

EA

AQ2W-AA2VAAXP Surf Wall,Anlg,2%RH,VOC,PIRNo Tmp
$570.00 /

EA

AQ2W-AA2VABD Surf Wall,Anlg,VOC,2%RHTmp Xmit,OLED
$600.00 /

EA

AQ2W-AA2VABDP Surf Wall,Anlg,2%RH,VOC,PIRTmp Xmit,OLED
$645.00 /

EA

All prices shown are excluding tax unless otherwise specified.
