P6 Pro Series

P6 Universal Nema 4 Pressure Sensor
Higher Reliability, Faster Installation, Superior Accuracy | Sense the Difference

0-5”, 15”, and 40” W.C. ranges; 10 selectable sub-ranges
0-1250, 3750, and 10000 Pa ranges; 10 selectable sub-ranges
LCD display and LED indicator
Nema 4X enclosure (Duct/port version)
  • Selectable 4-20 mA loop-powered, 4-20 mA 3-wire, 0-5VDC, 0-10VDC for compatibility
  • 10 field selectable pressure ranges to address a wide range of applications with high resolution
  • Field selectable Pa or WC” display
  • Zero calibration push button and remote contact input
  • Models for duct or remote probe applications
  • Selectable fast/slow response rate (2s fast, 8s slow)
  • Non-position sensitive for easy placement
  • Conduit ready or use included water tight cable gland
  • LED: Power heartbeat, ,momentary rapid flash = autozero complete, continual rapid flash = 110% over pressure

Description

The P6 universal dry media pressure transmitter accurately measures multiple ranges optimized for building (zone) pressure, filter measurement, and static duct applications. Selectable outputs and uni/bi directional readings reduce inventory. Conduit ready Nema 4 enclosure for harsh environments.

Applications

  • Building (zone) pressure
  • Filter condition measurement
  • Duct/static
  • Wash down environments
Product Price Quantity
P6-0500-1LP Dry Diff. Press. 5" EnclosedUniversal w/ LCD, Duct Probe
$381.60 /

EA

P6-0500-1LX Dry Diff. Press. 5" EnclosedUniversal w/ LCD, Barbs
$349.80 /

EA

P6-1500-1LP Dry Diff. Press. 15" EnclosedUniversal w/ LCD, Duct Probe
$381.60 /

EA

P6-1500-1LX Dry Diff. Press. 15" EnclosedUniversal w/ LCD, Barbs
$349.80 /

EA

P6-4000-1LP Dry Diff. Press. 40" EnclosedUniversal w/ LCD, Duct Probe
$381.60 /

EA

P6-4000-1LX Dry Diff. Press. 40" EnclosedUniversal w/ LCD, Barbs
$349.80 /

EA

All prices shown are excluding tax unless otherwise specified.
