CT1 Series
CT1R & CT1W CO2 Temp Recessed & Wall
Higher Reliability, Faster Installation, Superior Accuracy | Sense the Difference
Attractive low profile design CT1R drywall clamps make installation simple without a junction box CT1W Tamper proof push-in lock tabs - great for schools! Made in America - Best in industry 7-year warranty!
Optional LCD with field calibration menu
High-accuracy NDIR CO2 element
Sense up to 10,000 ppm CO2 or choose Dual Channel element
Integrated setpoint relay on LCD versions
Optional "wall" enclosure for surface-mount applications
- Mounts easily in standard wall plates
- Innovative drywall clamps allow unobtrusive and secure
mounting without a junction box - Ideal for schools and institutional environments
- Analog output provides 0-5,V, 0-10V, or 3-wire 4-20mA
- Thermistor outputs for temperature optional
- Optional LCD display
- Optional Dual Channel element
- Non-dispersive infrared sensing element (NDIR)
- 15+ year life expectancy on CO2 sensing element
- High Accuracy: ± 30 ppm, ± 3% of reading
- Auto-calibration mode returns sensor to baseline values
Description
The Senva CT1 Series comes in our newly engineered enclosure, making it the most attractive and quickest-installed CO2 sensor on the market. Designed with a selectable analog output and a variety of thermistor options allows flexibility on-site and ease of ordering. It mounts easily in any junction box, or it can be unobtrusively mounted directly to drywall using Senva’s built-in drywall clamps. Save installation time and energy costs with this versatile product.
Applications
- Controlling ventilation in response to occupancy
- Facilitating compliance with ASHRAE 62.1 standard for air quality
- Offices, conference rooms, and public assembly areas
- Greenhouses, hospitals, convenience stores, etc (dual channel version)
